AIR XD 10 1x10 2-Way Active Extended Definition Loudspeaker
AIR XD 10 1x10 2-Way Active Extended Definition Loudspeaker
Couldn't load pickup availability
Overview
- The PreSonus AIR XD 10 is a full-range active loudspeaker designed for professional use, delivering extended-definition sound, high SPL, and precise tonal balance for any application. Its custom 10-inch low-frequency driver features an enlarged 2.36” voice coil for efficient power handling and extended low-end response down to 55 Hz, producing tight, dynamic bass with minimal distortion. The 1-inch high-frequency driver uses a PEEK diaphragm, offering exceptional stiffness, wear resistance, and high-temperature tolerance, resulting in clear, detailed, and ultra-responsive highs even under prolonged, high-output operation.
- Powered by 1,500W of efficient Class D amplification, the AIR XD 10 can reach up to 130 dB SPL while maintaining clarity and headroom. Onboard DSP presets, ±10 dB EQ, and performance tuning modes allow quick adjustment for speech, music playback, FOH, or monitor use. A full-color 2.6” LCD provides intuitive metering, system control, and rapid access to all settings.
- Built-in Bluetooth with TWS Bridge Mode enables effortless wireless stereo pairing, making it ideal for mobile DJs, corporate events, and fast setups. The integrated mixer includes combo mic/line and aux inputs, allowing seamless connectivity and versatile signal routing. Rugged enclosures with ergonomic handles and multiple mounting options make the AIR XD 10 as portable as it is powerful, whether flown, pole-mounted, ground-stacked, or used as a floor monitor.
Overview
Features
- Custom 10-inch low-frequency driver with enlarged 2.36” voice coil for extended low-end response down to 55 Hz
- 1-inch High-frequency compression driver with PEEK diaphragm for clear, detailed, and durable highs
- 1,500W Class D bi-amplification for clean, efficient power and up to 130 dB SPL
- Onboard DSP with performance presets, ±10 dB EQ, and tuning modes for speech, music, FOH, or monitor use
- Full-color 2.6" LCD for fast, intuitive metering and system control
- Built-in Bluetooth with TWS Bridge Mode for true wireless stereo pairing
- Integrated 3-channel mixer with combo mic/line and aux inputs for flexible connectivity
- Rugged, portable enclosure with ergonomic handles and multiple mounting options: flown, pole-mounted, ground-stacked, or floor wedge
Downloads
Don't see what you're looking for?
Log in to your my.presonus.com account.
Documentation
Don't see what you're looking for?
Log in to your my.presonus.com account.
Specs
Electronics
Auxiliary Input
1/8 in (3.5 mm) Stereo
Bluetooth
Bluetooth® V5.0
Channels
Three
Connectivity
Bluetooth
Inputs
Four - (2 x XLR/TRS Mic/Line Combo, 1 x 1/8” TRS Stereo, Bluetooth Stereo)
Line Out
One - 1 x XLR Mix Out
Power Consumption
3.3A (230V-50 Hz), 6.6A (120V)
VoltageRequirements
100-240 VAC, 50-60 Hz
General
Amplifier Type
Class-D
Color
Black
Product Name
AIR XD 10 2-Way Active Sound-Reinforcement Loudspeaker
Series
AIR
Hardware
Audio Controls
Gain, Volume, Hi/Lo EQ
Cabinet Material
H-PP Molded
Cooling
Passive radiator
Grille Material
1.2 mm Steel
HF Powere
468W
HF Transducers
1” Compression
Handle
1 Top
LF Power
1060W
LF Transducers
10” (2.36” Voice Coil)
Pole Socket
Dual Position (0˚, 7.5˚)
Inputs
Line Input Connection Type
XLR/TRS Mic/Line Combo
Line Inputs Impedance
30K ohm
Line Inputs Maximum Level
+14dBu
Microphone Preamp Input Impedance
30K ohm
Measurements
Product Depth
11.5" (29.1 cm)
Product Height
20.3" (51.6 cm)
Product Height/Length
20.3" (51.6 cm)
Product Weight
30.9 lbs (13.9 kg)
Product Width
11.8" (30.0 cm)
Miscellaneous
DSP Features
Speaker modes, Location, Bass, Treble
Power Cable
IEC
Protections
Output limiter
Suspension
M10 Suspension Points, Flypoints: 2 Top, 1 Back
Output
Line Outputs Connection Type
XLR Male, Balanced
Performance
Peak SPL
130 dB
Total Power Output
1500 Watts
Speakers
Coverage Pattern
90 degree (H) x 60 degree (V)
Crossover Frequency
2.2 kHz
Speaker Type
Active 2-Way
Total Impedance
NA
